Chapter4HardwareBoard
TABLE42LEDFUNCTIONSOFRS-89S1-4XGE-XFPCARD
LEDType
StateDescription
LINK
On:portlinkiscreated
Off:theportisdisconnectedfromothers
ACT
Off:nodatatransmissionorreceptionontheport
Flash:datatransmissionandreceptionontheport
RS-89S1-8XGE-XFPCard
FunctionRS-89S1-8XGE-XFPcardprovideseightXFPinterfacesfor10gi-
gabitEthernetopticalinterface.
FrontPanelFrontpanelisshowninFigure32.
FIGURE32FRONTPANELOFRS-89S1-8XGE-XFP
InterfacesOpticalmoduleusedbyRS-89S1-8XGE-XFPcardishot-swap
XFPopticalmodule.Eachportsupportsvarioustransmission
distances.InterfacecharacteristicsareshowninT able43.
TABLE43INTERFACECHARACTERISTICSOFRS-89S1-8XGE-XFPCARD
InterfaceType
Characteristics
10GBASE-SR
(XFP-M300)
LCconnector ,single-modeopticalber ,withthe
wavelengthof850nm,maximumtransmission
distanceis300m
Transmissionpower:-7.3dBm~-1dBm,receiving
sensitivity:≥-11.1dBm
10GBASE-LR
(XFP-L10K)
LCconnector ,single-modeopticalber ,withthe
wavelengthof1310nm,maximumtransmission
distanceis10km
Transmissionpower:-6dBm~-1dBm,receiving
sensitivity:≥-10.3dBm
10GBASE-ER
(XFP-L40K)
LCconnector ,single-modeopticalber ,withthe
wavelengthof1550nm,maximumtransmission
distanceis40km
Transmissionpower:-2dBm~1dBm,receiving
sensitivity:≥-11.3dBm
LEDsThereare16LEDsinthefrontpanelofRS-89S1-8XGE-XFPcard.
FunctionsoftheseLEDsaredescribedinTable44.
CondentialandProprietaryInformationofZTECORPORATION47

Zte ZXR10 8900 Series Specifications

General

Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T
Layer Support	Layer 2 and Layer 3
VLAN Support	4K VLANs
QoS	8 priority queues per port
Management	CLI, Web, SNMP, RMON
Power Supply	AC or DC
Redundancy	Power supply redundancy, fan redundancy
