Chapter4HardwareBoard
TABLE92INTERFACECHARACTERISTICSOFRS-89E3B-2XGE-XFPCARD
InterfaceType
Characteristics
10GBASE—SR
(XFP-M300)
LCconnector ,single-modeber ,withthe
wavelengthof850nm,maximumtransmission
distanceis300m
Transmissionpower:-7.3~-1dBm,receiving
sensitivity:≥-11.1dBm
10GBASE-LR
(XFP-L10K))
LCconnector ,single-modeber ,withthe
wavelengthof1310nm,maximumtransmission
distanceis10Km
Transmissionpower:-6~-1dBm,receiving
sensitivity:≥-10.3dBm
10GBASE-ER
(XFP-L40K)
LCconnector ,single-modeber ,withthe
wavelengthof1550nm,maximumtransmission
distanceis40km
Transmissionpower:-2~1dBm,receiving
sensitivity:≥-11.3dBm
LEDs4indicatorsonfrontpanelofRS-89E3B-2XGE-XFPcardcorre-
spondto2xedEthernetopticalinterfaces.Functionsofthese
LEDsaredescribedinT
able93.
TABLE93RS-89E3B-2XGE-XFPCARDFRONTPANELLEDFUNCTION
DESCRIPTION
LEDType
StateDescription
LINK
On:portlinkiscreated
Off:theportisdisconnectedfromothers
ACT
Off:theportisdisconnectedfromothers
Flash:datatransmissionandreceptionontheport
RS-89E3B-4XGE-XFPCard
FunctionRS-89E3B-4XGE-XFPcardprovides410GEthernetopticalinter-
faces.
FrontPanelFrontpanelisshowninFigure54.
FIGURE54RS-89E3B-4XGE-XFPFRONTPANEL
InterfacesRS-89E3B-4XGE-XFPcardusehot—swapXFPopticalmodule.
Eachportsupportsvarioustransmissiondistances.Interface
characteristicsareshowninTable94.
CondentialandProprietaryInformationofZTECORPORATION77
