Zte ZXR10 8900 Series Hardware Manual

ZXR108900SeriesHardwareManual
FrontPanelFrontpanelisshowninFigure56.
FIGURE56FRONTPANELOFRS-89H1-24GE-SFP
InterfacesOpticalmoduleusedbyRS-89H1-24GE-SFPinterfaceishot-swap
SFPopticalmodule.Eachportsupportsdifferenttransmissiondis-
tancesusedbygigabitEthernet.CharacteristicsareshowninTable
98.
TABLE98INTERFACECHARACTERISTICSOFRS-89H1-24GE-SFPCARD
InterfaceType
Characteristics
1000BASE-SX
SFP-M500
LCconnector ,multi-modeber ,wavelength:
850nm,max.transmissiondistance:500m
Transmissionpowerrange:-9.5Bm~-4
dBm;receivingsensitivity:≥-18dBm
1000BASE-LXSFP-S10K
LCconnector ,single-modeber .Wavelength:
1310nm.Max.transmissiondistance:
10km
Transmissionpowerrange:-9.5Bm~-3
dBm;receivingsensitivity:≥-20dBm
1000BASE-LXSFP-S40K
LCconnector ,single-modeber .Wavelength:
1310nm.Max.transmissiondistance:
40km
Transmittingpowerrange:-4dBm~0dBm;
receivingsensitivity:≥-22dBm
1000BASE-LHSFP-S80K
LCconnector ,single-modeber .Wavelength:
1550nm.Max.transmissiondistance:
80km
Transmittingpowerrange:0dBm~5dBm;
receivingsensitivity:≥-22dBm
1000BASE-LH
SFP-S120K
LCconnector ,single-modeber .Wavelength:
1550nm.Max.transmissiondistance:
120km
Transmittingpowerrange:5dBm~9dBm,
receivingsensitivity:≥-30dBm
LEDTypeThereare24LEDsonthefrontpanelofRS-89H1-24GE-SFPcard.
EachinterfacecorrespondstooneLED.FunctionsoftheseLEDs
aredescribedinTable99.
80CondentialandProprietaryInformationofZTECORPORATION

Zte ZXR10 8900 Series Specifications

General

Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T
Layer Support	Layer 2 and Layer 3
VLAN Support	4K VLANs
QoS	8 priority queues per port
Management	CLI, Web, SNMP, RMON
Power Supply	AC or DC
Redundancy	Power supply redundancy, fan redundancy
