Chapter4HardwareBoard
TABLE99LEDFUNCTIONSOFRS-89H1-24GE-SFPCARD
LEDType
StateDescription
LINK/ACT
On:interfacelinkiscreated
Off:interfaceisdisconnectedfromothers
Flash:datatransmissionandreceptionin
theinterface
RS-89H1-48GE-SFPCard
FunctionRS-89H1-48GE-SFPcardimprovesL2/3functionsbasedon
RS-89S2-48GE-SFPcard,showslargeentrysizeandprovides
MPLSfunction.Itcanprovide48gigabitEthernetopticalinter-
facesandimplementL2-L7packetprocessingtomeetcomplicated
applicationsinactualnetworking.
FrontPanelFrontpanelisshowninFigure57.
FIGURE57FRONTPANELOFRS-89H1-48GE-SFP
InterfacesOpticalmoduleusedbyRS-89H1-48GE-SFPinterfaceishot-swap
SFPopticalmodule.Eachportsupportsdifferenttransmissiondis-
tancesusedbygigabitEthernet.CharacteristicsareshowninTable
100.
TABLE100INTERFACECHARACTERISTICSOFRS-89H1-48GE-SFPCARD
InterfaceType
Characteristics
1000BASE-SX
SFP-M500
LCconnector ,multi-modeber ,wavelength:
850nm,max.transmissiondistance:500m
Transmissionpowerrange:-9.5Bm~-4
dBm;receivingsensitivity:≥-18dBm
1000BASE-LXSFP-S10K
LCconnector ,single-modeber .Wavelength:
1310nm.Max.transmissiondistance:
10km
Transmissionpowerrange:-9.5Bm~-3
dBm;receivingsensitivity:≥-20dBm
1000BASE-LXSFP-S40K
LCconnector ,single-modeber .Wavelength:
1310nm.Max.transmissiondistance:
40km
Transmittingpowerrange:-4dBm~0dBm;
receivingsensitivity:≥-22dBm
