Zte ZXR10 8900 Series Hardware Manual

ZXR108900SeriesHardwareManual
LEDTypeThereare48LEDsonfrontpanelofRS-8900-44FE4GE-SFPcard,
indicatingworkingstatesof48Ethernetopticalinterfaces.There
isonegreenLINK/ACTindicatorundereachSFPopticalinterface.
FunctionsoftheseLEDsaredescribedinT
able133.
TABLE133LEDFUNCTIONSOFRS-8900-44FE4GE-SFPCARD
LEDType
StateDescription
LINK/ACT
On:interfacelinkiscreated
Off:interfaceisdisconnectedfromothers
Flash:datatransmissionandreceptionin
theinterface
RS-8900-44FE4GE-RJ4SFPCard
FunctionRS-8900-44FE4GE-RJ4SFPcardprovides44100mbpselectrical
interfacesand4gigabitopticalinterfacesforusermixinguse.It
supportsthefunctionsinLayer2andLayer3,canprocessser-
vicesinL4-L7,implementsallbasicservicesinL3,andhasbasic
ACLfunction,extendedACLfunction,hybridACLfunction,IPV6
functionandotherfunctions.
FrontPanelFrontpanelisshowninFigure73.
FIGURE73FRONTPANELOFRS-8900-44FE4GE-RJ4SFP
InterfacesOpticalmoduleusedbyRS-8900-44FE4GE-RJ4SFPcardis
hot—swapXFPopticalmodule.Eachportsupportsdifferent
transmissiondistances.CharacteristicsareshowninT able134.
TABLE134INTERFACECHARACTERISTICSOFRS-8900-44FE4GE-RJ4SFP
InterfaceType
Characteristics
1000BASE-SX
SFP-M500
LCconnector ,multi-modeber ,wavelength:
850nm,max.transmissiondistance:500m
Transmissionpowerrange:-9.5Bm~-4
dBm;receivingsensitivity:≥-18dBm
1000BASE-LXSFP-S10K
LCconnector ,single-modeber .Wavelength:
1310nm.Max.transmissiondistance:
10km
Transmissionpowerrange:-9.5Bm~-3
dBm;receivingsensitivity:≥-20dBm
100CondentialandProprietaryInformationofZTECORPORATION

Zte ZXR10 8900 Series Specifications

General

Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T
Layer Support	Layer 2 and Layer 3
VLAN Support	4K VLANs
QoS	8 priority queues per port
Management	CLI, Web, SNMP, RMON
Power Supply	AC or DC
Redundancy	Power supply redundancy, fan redundancy
