MG Series Gateway Setup Manual ver 306.X (0000000272)
Revision 20 Jul. 12, 11
© 2011 Zultys, Inc. No reproduction of distribution without permission
Page 41 of 42
13.4 Silence after disconnect (FXS ports)
This option allows switching silence on FXS Ports after
receiving disconnect from the other side. The silence is used with special paging
devices, which disconnect on silence.
To set silence as disconnect indication enter
URI: http://xx.xx.xx.xx/xml?method=gw.config.set&id603=1
To set busy tone as disconnect indication enter
URI: http://xx.xx.xx.xx/xml?method=gw.config.set&id603=0
To read back the current value:
http://xx.xx.xx.xx/xml?method=gw.config.get&pass=voip&id=603
The setting affects all FXS ports
14 Fail Over
14.1 SIP Failure between the MG and the MX
In the event SIP communications is lost between the MG and the MX, incoming
calls can be routed to the FXS Ports via the Routing Table. The recommended entry
is
IP xxxx ROUTE FXS 1-4/g
This will route all incoming calls that have that are exactly 4
digits in length to FXS Ports 1-4 simultaneously.
or shorter than
section.
14.2 Power Fail MG8SO (4FXO/4FXS)
In the event of a power failure for the MG8SO (which has 4 FXS Ports, and 4 FXS
Ports).
section.
FXO Port 1 will be relay switched to FXS Port 1
FXO Port 2 will be relay switched to FXS Port 2
FXO Port 3 will be relay switched to FXS Port 3
FXO Port 4 will be relay switched to FXS Port 4
