MG Series Gateway Setup Manual ver 306.X (0000000272)
Revision 20 Jul. 12, 11
© 2011 Zultys, Inc. No reproduction of distribution without permission
Page 29 of 42
10.3 Advanced FXO settings
Suggested settings are
Caller ID detection mode: After ringing A
- the
-
- -
indicates the current selected trunk number and m indicates the total
number of trunks.
Select if this trunk registers with the SIP registration server. By default,
this is selected.
The authentication password for register of this line must be entered
here corresponding to the password set for the same device ID on MX.
Note: The following features are valid only in SIP protocol. When the gateways use MGCP
protocol, the control of all call services is provided by the proxy server without the need of
setting.
The gateways provide two scenarios for handling incoming calls of
FXO port:
port, the gateways will provide the second dial tone and route the
call according to the extension number pressed in. Note: dialing
tone or voice prompt file can be changed by user.
gateways will route the call to a FXS port according to the DID
number bound with the port. Note: Setting a number to be bound is
required or this setting is invalid.
Polarity reversed
signal detection
If a PSTN line supports reverse polarity, make a selection here. Or this
setting is invalid. By default, this is not selected.
Select if the detection function of caller ID for this FXO port is
enabled. By default, this is selected.
Select if this FXO port bars outgoing call service to PSTN. By default,
this is not selected.
Select if echo cancellation is enabled for this FXO line. By default, this
is selected.
After making an outgoing call from a FXO port, the gateway will send
a 200 OK message to the platform with delay if this parameter is
selected. If unselected, the system sends a 200 OK message to the
platform after off hook on the FXO port. Used with the configuration
