2.4 Completion
Remember to seal the cable passage hole properly to avoid 2N IP Vario
®
moisture in-leak and damage to electronics due to condensation.
Make sure that the wires inside are not squeezed and insert the 2N IP Vario
®
plastic top cover (a transparent plastic mould) carefully making its contacts plug
into the electronics board connectors. Push the plastic cover into position
moderately. If the part swings over an obstacle or one corner is higher than the
others, remove the cover and find the obstacle. Then tighten the corner screws
properly.
Mounting the metal sheet cover follow the steps included in the subsection
dedicated to name plate removal. Make sure that the cover fits well and is
perfectly flat. If its bottom part is loose, the mounting wall is probably uneven.
Support the corners to avoid bending.2N IP Vario
®
Caution
An improper mounting may significantly deteriorate the button function.
A poor outdoor mounting may cause water in-leak and damage to the
electronics.
