Outdoor Installation Rules
Always connect button backlighting – it is used for heating.
The joint between the roof module and the wall must be filled with a waterproof
cement to prevent water in-leak (see Figure 2.5).
Water must not leak in along or around the cables.
Warning
Make sure that all the holes are filled with a waterproof material – top,
around the cables and screws - and that a side sealing is ensured.
Name Tag Material and Printing
Each package includes a sheet of transparent foil for laser printing. Cut 2N IP Vario
®
the printed foil into pieces and insert the labels in the name plates. Do not use paper
to avoid water in-leak and paper damage.
Red arrows are printed on the name plate. Make sure that the text and the arrow do
not overlap. We recommend you to use a template (MS Word) available in section
Downloads for printing.
Flush Mounting
Follow the installation instructions included in the flush mounting box delivery.
Caution
The warranty shall not apply to product failures and defects caused by
improper installation (contrary to these instructions). The manufacturer
is neither liable for damages caused by theft within an area that is
accessible after the attached electric lock is switched. The product is not
designed as a burglar protection device except when used in
combination with a standard lock, which has the security function.
