Dynamic IP Address Setting
Connect to the power supply (or, disconnect and reconnect it if already 2N IP Vario
®
connected).Follow the instructions below to enable automatic getting of network
parameters from the DHCP server:
Wait for the first acoustic signal
Press following buttons sequentially:
2, 1, 1, 2, 2, 3 for 3-buttons models
5, 4, 4, 5, 5, 6 for 6-buttons modely
The acoustic signal indicates mode switching.
Wait until the device is restarted automatically.
Note
The 2, 1, 1, 2, 2, 3 sequence must be entered within 30 seconds after the
first sound signal for security reasons. The inter-digit delay may be 2 s at
most.
2N IP Vario
®
gets the IP address upon restart only if the DHCP server is configured
properly.
