RFID card reader
Optional (Part No. 9137430E)
Equipped with two relay outputs, two inputs and Wiegand interface
Supported cards 125 kHz:
EM4100, EM4102, HID Prox
Mechanical properties
Working temperature: −20 °C to 55 °C
Working relative humidity: 10 % – 95 % (non-condensing)
Storing temperature:−40 °C to 70 °C
Dimensions: (210 x 100 x 29) mm
Weight: 500 g
Covering level:
IP53 when the roof is used (see Mounting Accessories)
IP50 when the roof is not used
Resistance level: IK08
