3B6 COBO View Tech HC115 - Basic Procedures; How to Move to Main Screen Visualization [Operative Mode Activated]; How to Move to Pin Out Screen Visualization; How to Move to Main Screen Visualization [Diagnostic Mode Activated]

14
I CLS
-
LMI
-
Calibration
I
ENGLISH
3
3 Basic Procedures
3.1 How To Move To Main Screen Visualization [Operative Mode Activated]
•
••
• Switch on the Unit.
•
••
• After Software Opening Screen, software automatically moves to Main Screen Visualization -
OPERATIVE MODE, as you can see in the Control Area.
•
••
• Select the Operative Mode by pressing the key button
•
••
• Press to confirm the operative mode.
3.2 How To Move To ‘Pin Out’ Screen Visualization
•
••
• Press to enter the ‘Pin Out’ Screen Visualization.
3.3 How To Move To Main Screen Visualization [Diagnostic Mode Activated]
•
••
• From ‘Pin Out’ Screen Visualization, press again.
•
••
• You return to Screen Visualization, but in DIAGNOSTIC MODE, as you can see in the Control Area.
3.4 How To Return To Main Screen Visualization [Operative Mode
Activated]
•
••
• From Main Screen Visualization - DIAGNOSTIC MODE, press (ESC).
•
••
• You return to Main Screen Visualization - OPERATIVE MODE.
3.5 How To Regulate Display Brightness
•
••
• To increase Brightness press .
•
••
• To reduce Brightness press
