5.13 [31 COG Mode] Centroids Memorization
This procedure memorizes centroids with respect to the sections of the boom. The user must follow the instruction that
the display shows during the procedure.
NOTE!
This menu procedures changes according to the machine type and model.
PROCEDURES STATUS
IN THE CONTROL AREA
Follow steps in 3.5 paragraph to select and enter the menu parameters
Empty Moment – COG Mode
Pressing the
keys, seek the page as shown on the right: “COG Mode”
menu.
Press to get in.
A 78 L 8.1 W 1.2
31 COG Mode
Press for exit and delete the operation;
Press
or for scroll steps without execute.
Press to confirm an operation.
When you entry inside this page, software tells us how to continue.
In general first Row shows the procedure and the second Row shows which key you
have to use for execute the procedure.
“START PROCEDURE”: shows you what procedure you have to begin.
“ENTER TO START” : press to continue after having completed
procedure.
COG PROCEDURE
ENTER TO START
