If you confirm this operation ,the previous pressure table will delete.
If the system allow the action, the system will go immediately to the next step.
”CLOSE MAIN BOOM”: close all boom section.
”ENTER TO START”: press to Start next step.
if the system allow the action, the system will go immediately to the next step.
Close Main Boom
ENTER TO START
“Move A1 at 80” : move the boom until the angle 80 degree;
”ENTER TO START” : press key to continue.
If the system allow the action, the system will go immediately to the next step.
Note important:
if your machine doesn’t reach this position, move the main boom to its
maximum possible angle , press enter to begin procedure.
Move A1 at 80
ENTER TO START
”Move A1 at 0” : move the boom slowly until the angle 0 degree and press
immediately after this operation key to continue.
If the system allow the action, the system will go immediately to the next step.
Move A1 at 0
ENTER TO START
Remain in this state until the boom doesn't reach 0.
Then, press to terminate and Exit from procedure.
Move A1 at 0
In Progress…
Now the procedure calibration is finished and you can save
the calibration by “SAVE” menu.
OPTIONS
01 Save
