Diagnostic System Internal Working Conditions Monitoring
4.2 Length And Angle Data
Pressing once again the display in the Control Area shows the length (S1) values:
By pressing scrolling the Auto-Diagnostic System Menu in the Control Area.
To every pressure of it comes visualized for 2 second ones under menu.
Choose and shows the individual Length and Angle Data summary:
The displayed parameters are as follows:
•
••
• S1adc : Value (bit) directly from the potentiometer of the Length 1
•
••
• S1act : Value (centimeters) of the main boom length
Pressing once again the display in the Control Area shows the main boom angle (A1) values:
The displayed parameters are as follows:
•
••
• A1adc : Value (bit) directly from the angle sensor
•
••
• A1act: Value (degree x 10) of the main boom angle
S1adc S1act
400 1870
A1adc A1act
700 780
