4 Auto-Diagnostic System Internal Working Conditions Monitoring
4.1 Hydraulic Pressures Data
Enter in Main Screen Visualization - DIAGNOSTIC MODE [see par. 3.3].
By pressing scrolling the Auto-Diagnostic System Menu in the Control Area.
To every pressure of it comes visualized for 2 second ones under menu.
Choose and shows the individual hydraulic pressures summary:
The displayed parameters are as follows:
•
••
• PL1adc : Value (bit) reads directly from the pressure sensor
•
••
• PL1act : Value of the pressure on the bottom side
The displayed parameters are as follows:
•
••
• PL2adc : Value (bit) reads directly from the pressure sensor
•
••
• PL2act : Value of the pressure on the bottom side
The displayed parameters are as follows:
•
••
• PH1adc : Value (bit) reads directly from the pressure sensor
•
••
• PH1act : Value of the pressure on the rod side
PH1adc PH1act
100 200
PL1adc PL1act
300 550
PL2adc PL2act
300 550
