System Specifications 17
System
Specifications
Table 3 contains the system specifications of the 2924-PWR series
switch.
Additional specifications can be found in Appendix B “Device
Specifications and Features”.
Table 3 System specifications of the Switch 2924PWR series switch
Specification Switch 2924-PWR Plus 24-Port 3CBLSG24PWR
Physical dimensions
(H×W×D)
44×440×265 mm (1.73 17.3 10.43 in.)
Weight 3.6 kg (7.9 lb)
Console port One Console port
Gigabit Ethernet ports on
the front panel
24 × 10/100/1000 Mbps Ethernet ports
Four Gigabit SFP Combo ports
AC Input voltage Rated voltage range: 100–240 VAC, 50/60 Hz
Power consumption
(full load)
350 W
Operating temperature 0 to 40 °C (32 to 113 °F)
Relative humidity 10 to 90% noncondensing
