CHAPTER 8: CONFIGURING VLANS
113
Select Membership Type — Displays the membership type for
each VLAN. The possible field values are:
Untagged — Indicates the interface is an untagged member of
the VLAN.
Tagged — Indicates the interface is a tagged member of a
VLAN. VLAN tagged packets are forwarded by the interface.
The packets contain VLAN information.
Not a Member — Indicates the interface is not a member of the
VLAN.
Not Available for Selection — Indicates the interface is not
available for selection.
Select All — Allows the user to select all ports to be added to the
VLAN.
Select None — Removes the ports selected.
To add ports to a VLAN
1 Select a VLAN to modify.
2 Select the membership type for the selected port.
3 Select ports to be added to the selected VLAN.
4 Click Apply. The selected ports are added to the VLAN, and the
device is updated.
