CHAPTER 1: GETTING STARTED
3
Table 1 Hardware Features (continued)
Feature Switch 2948
Flow Control In full duplex operation, all ports are supported.
The Switch 2948 ports are capable of receiving,
but not sending pause frames.
Traffic Prioritization Supported (using the IEEE Std 802.ID, 1998
Edition): Four traffic queues per port
Ethernet, Fast Auto-negotiating 10/100/1000BASE-T ports
and Gigabit
Ethernet Ports
SFP Ethernet Ports Supports fiber Gigabit Ethernet long-wave (LX),
and fiber Gigabit Ethernet short-wave (SX)
transceivers in any combination.
Mounting 19-inch rack or standalone mounting
Figure 1 shows the front panel of the Switch 2948-SFP Plus 48-Port
unit.
Figure 1 Switch 2948 SFP 48-Port—front panel
Front Panel Detail
