CHAPTER9: CONFIGURING IP AND MAC ADDRESS INFORMATION
130
Aging Time —Indicates that the MAC address is aged out or not.
NOAGED — Indicates that the Address Table entry is not aged out.
AGING — Indicates that the Address Table entry is aged out.
2 Select the port(s) to display MAC address on the table.
3. Select the MAC addresses to remove.
4 Click Remove. The selected MAC addresses are removed from the
MAC address table, and the device is updated.
The Address Table Remove Page allows the network manager to remove
current MAC addresses from the Address Table.
The monitor users have no access to this page.
To remove Address Tables:
1 Click Monitoring > Address Table > Remove. The Address Table
Remove Page opens.
Figure 69 Address Table Remove Page
Remove address
Table
To Next Page
