4.0 MEASURE SAMPLE
4.01 What is MEASURE SAMPLE
4.02 How to Test using MEASURE SAMPLE
4.01 What is MEASURE SAMPLE
MEASURE SAMPLE allows as many readings as required but does not store the data for later use. If a 3M
Clean-Trace Luminometer printer is used, results may be printed as they are produced as long as the printer is
turned on and connected while the measurement is performed.
NOTE: To store the data, refer to Section 5 PROGRAM MODE.
4.02 How to Test Using MEASURE SAMPLE
Turn the 3M™ Clean-Trace™ NGi Luminometer on. When
initialized the screen will display the MAIN MENU:
The cursor will be pointing at MEASURE SAMPLE. Insert a 3M
test device into the 3M™ Clean-Trace™ NGi Luminometer (see
section 2.06)
Measuring Samples
To measure a sample, press the SELECT key. The screen will
display the word MEASURING and a series of "count-up" blocks
will appear.
The screen will then display the result in Relative Light Units
(RLU).
