14 | Getting Started
Aprisa SRx User Manual 1.3.0
Phase 3:
Establishing the link
1.
If radio’s IP address is not the default IP address (169.254.50.10 with a subnet
mask of 255.255.0.0) and you don’t know the radio’s IP address see ‘Command
Line Interface’ on page 259.
Page 259
2.
Connect the Ethernet cable between the radio’s Ethernet port and the PC.
3.
Confirm that the PC IP settings are correct for the Ethernet connection:
 IP address
 Subnet mask
 Gateway IP address
Page 67
4.
Open a web browser and login to the radio.
Page 71
5.
Set or confirm the RF characteristics:
 TX and RX frequencies
 TX output power
Page 92
6.
Compare the actual RSSI to the expected RSSI value (from your path planning).
7.
Align the antennas.
Page 265
8.
Confirm that the radio is operating correctly; the OK, MODE and AUX LEDs are
green.
