87VCCX-454 Controller Technical Guide
APPENDIX C: BACNET GUIDE
Analog Inputs
VCCX-454 ANALOG INPUTS
Parameter Object Description Limits
RM-454-Z 2 Comp VFD
Alarms 2
AI: 177 Current RM-454-Z 2 Comp VFD Alarms 2 See RM-454-Z Alarms 2 Bits on page 103
RM-454-Z 2 Comp VFD Drive
Status
AI: 178 Current RM-454-Z 2 Comp VFD drive status See RM-454-Z Drive Status Bits on page
102
RM-454-Z 2 Compressor
Current
AI: 179 Current reading in Amps that the RM-454-Z 2 compressor
is using
RM-454-Z 2 Discharge Line
Temp
AI: 180 Current RM-454-Z 2 discharge line temperature
RM-454-Z 2 Faults AI: 181 Current RM-454-Z 2 Faults See RM-454-Z Faults Bits on page 102
RM-454-Z 2 Lockouts AI: 182 Current RM-454-Z 2 Lockouts See RM-454-Z Lockouts Bits on page 102
RM-454-Z 3 Condenser Fan AI: 183 Current RM-454-Z 3 condenser fan signal
RM-454-Z 3 Reheat Valve 1 AI: 184 Current RM-454-Z 3 Reheat Valve 1 position
RM-454-Z 3 Discharge
Pressure
AI: 185 Current RM-454-Z 3 discharge pressure
RM-454-Z 3 Suction Pressure AI: 186 Current RM-454-Z 3 Suction Pressure
RM-454-Z 3 Suction Line
Temp
AI: 187 Current RM-454-Z 3 Suction Line Temperature
RM-454-Z 3 Saturation Temp AI: 188 Current RM-454-Z 3 Saturation Temperature
RM-454-Z 3 Superheat AI: 189 Current RM-454-Z 3 Superheat temperature
RM-454-Z 3 EEV Position AI: 190 Current RM-454-Z 3 EEV valve position
RM-454-Z 3 Suction Pressure
2
AI: 191 Current RM-454-Z 3 Suction pressure 2
RM-454-Z 3 Suction Line
Temp 2
AI: 192 Current RM-454-Z 3 Suction Line Temperature 2
RM-454-Z 3 Saturation Temp
2
AI: 193 Current RM-454-Z 3 Saturation Temperature 2
RM-454-Z 3 Superheat 2 AI: 194 Current RM-454-Z 3 Superheat Temperature 2
RM-454-Z 3 EEV Position 2 AI: 195 Current RM-454-Z 3 EEV valve position 2
RM-454-Z 3 Warnings AI: 196 Current RM-454-Z 3 Warnings See RM-454-Z Warnings Bits on page 102
RM-454-Z 3 Discharge Line
Temp
AI: 197 Current RM-454-Z 3 discharge line temperature
RM-454-Z 3 Faults AI: 198 Current RM-454-Z 3 Faults See RM-454-Z Faults Bits on page 102
RM-454-Z 3 Lockouts AI: 199 Current RM-454-Z 3 Lockouts See RM-454-Z Lockouts Bits on page 102
RM-454-Z 4 Condenser Fan AI: 200 Current RM-454-Z 4 Condenser Fan Signal
RM-454-Z 4 VFD Comp Perc AI: 201 Current RM-454-Z 4 VFD Compressor Percentage
RM-454-Z 4 Discharge
Pressure
AI: 202 Current RM-454-Z 4 Discharge Pressure
RM-454-Z 4 Suction Pressure AI: 203 Current RM-454-Z 4 Suction Pressure
RM-454-Z 4 Suction Line
Temp
AI: 204 Current RM-454-Z 4 Suction Line Temperature
RM-454-Z 4 Saturation Temp AI: 205 Current RM-454-Z 4 Saturation Temperature
RM-454-Z 4 Superheat AI: 206 Current RM-454-Z 4 Superheat Temperature
RM-454-Z 4 EEV Position AI: 207 Current RM-454-Z 4 EEV valve position
RM-454-Z 4 Warnings AI: 208 Current RM-454-Z 4 Warnings See RM-454-Z Warnings Bits on page 102
RM-454-Z 4 Comp VFD
Alarms 1
AI: 209 Current RM-454-Z 4 Comp VFD Alarms 1 See RM-454-Z Alarms 1 Bits on page 103
Objects labeled AI are read-only.
