88VCCX-454 Controller Technical Guide
APPENDIX C: BACNET GUIDE
Analog Inputs
VCCX-454 ANALOG INPUTS
Parameter Object Description Limits
RM-454-Z 4 Comp VFD
Alarms 2
AI: 210 Current RM-454-Z 4 Comp VFD Alarms 2 See RM-454-Z Alarms 2 Bits on page 103
RM-454-Z 4 Comp VFD Drive
Status
AI: 211 Current RM-454-Z 4 Comp VFD drive status See RM-454-Z Drive Status Bits on page
102
RM-454-Z 4 Comp VFD
Compressor Current
AI: 212 Current reading in Amps that the RM-454-Z 4 compressor
is using
RM-454-Z 4 Discharge Line
Temp
AI: 213 Current RM-454-Z 4 discharge line temperature
RM-454-Z 4 Faults AI: 214 Current RM-454-Z 4 Faults See RM-454-Z Faults Bits on page 102
RM-454-Z 4 Lockouts AI: 215 Current RM-454-Z 4 Lockouts See RM-454-Z Lockouts Bits on page 102
RM-454-Z 5 Condenser Fan AI: 216 Current RM-454-Z 5 Condenser Fan Signal
RM-454-Z 5 VFD Comp Perc AI: 217 Current RM-454-Z 5 VFD Compressor Percentage
RM-454-Z 5 Discharge
Pressure
AI: 218 Current RM-454-Z 5 discharge pressure
RM-454-Z 5 Suction Pressure AI: 219 Current RM-454-Z 5 Suction pressure
RM-454-Z 5 Suction Line
Temp
AI: 220 Current RM-454-Z 5 Suction Line Temperature
RM-454-Z 5 Saturation Temp AI: 221 Current RM-454-Z 5 Saturation Temperature
RM-454-Z 5 Superheat AI: 222 Current RM-454-Z5 Superheat temperature
RM-454-Z 5 EEV Position AI: 223 Current RM-454-Z 5 EEV valve position
RM-454-Z 5 Warnings AI: 224 Current RM-454-Z 5 Warnings See RM-454-Z Warnings Bits on page 102
RM-454-Z 5 Comp VFD
Alarms 1
AI: 225 Current RM-454-Z 5 Comp VFD Alarms 1 See RM-454-Z Alarms 1 Bits on page 103
RM-454-Z 5 Comp Alarms 2 AI: 226 Current RM-454-Z 5 Comp VFD Alarms 2 See RM-454-Z Alarms 2 Bits on page 103
RM-454-Z 5 Comp VFD Drive
Status
AI: 227 Current RM-454-Z 5 Comp VFD drive status See RM-454-Z Drive Status Bits on page
102
RM-454-Z 5 Compressor
Current
AI: 228 Current reading in Amps that the RM-454-Z 5 compressor
is using
RM-454-Z 5 Discharge Line
Temp
AI: 229 Current RM-454-Z 5 discharge line temperature
RM-454-Z 5 Faults AI: 230 Current RM-454-Z 5 Faults See RM-454-Z Faults Bits on page 102
RM-454-Z 5 Lockouts AI: 231 Current RM-454-Z 5Lockouts See RM-454-Z Lockouts Bits on page 102
RM-454-Z 6 Condenser Fan AI: 232 Current RM-454-Z 6 condenser fan signal
RM-454-Z 6 Reheat Valve 1 AI: 233 Current RM-454-Z 6 Reheat Valve 1 position
RM-454-Z 6 Discharge
Pressure
AI: 234 Current RM-454-Z 6 discharge pressure
RM-454-Z 6 Suction Pressure AI: 235 Current RM-454-Z 6 Suction Pressure
RM-454-Z 6 Suction Line
Temp
AI: 236 Current RM-454-Z 6 Suction Line Temperature
RM-454-Z 6 Saturation Temp AI: 237 Current RM-454-Z 6 Saturation Temperature
RM-454-Z 6 Superheat AI: 238 Current RM-454-Z 6 Superheat Temperature
RM-454-Z 6 EEV Position AI: 239 Current RM-454-Z 6 EEV valve position
RM-454-Z 6 Suction Pressure
2
AI: 240 Current RM-454-Z 6 Suction pressure 2
RM-454-Z 6 Suction Line
Temp 2
AI: 241 Current RM-454-Z 6 Suction Line Temperature 2
RM-454-Z 6 Saturation Temp
2
AI: 242 Current RM-454-Z 6 Saturation Temperature 2
Objects labeled AI are read-only.
