Aastra MX-ONE - Page 11

Overview
Table 1 Size, Weight, and Voltage of MX-ONE Hardware
Pos.
Component
Product
Number
Width,
height, and
depth (mm)
Weight
(kg)
Input
Voltage
Output
voltage
Height
(U)
3)
Height
(M)
4)
A BYB 501
cabinet
(including
doors, side
and back
plates)
600 x 1,800 x
400
75
B Standard
cabinet
Locally
sourced
Battery
31 Ah (4
battery
blocks)
BKB 201
003/1
425 x 159 x
280
45
-48 V
DC
4 7.2
C
Battery
62 Ah (4
battery
blocks)
BKB 201
003/2
425 x 264 x
280
82
-48 V
DC
6 10.8
AC/DC
Unit
BZA 109 08/1
450 x 128 x
280
11.5 205 – 240
VAC
-48 V
DC
3 5.4
D
AC/DC
Unit
BZA 109 09/1
487 x 90 x
265
7.2 115 – 230
VAC
-48 V
DC
3 5.4
E DC/AC
Inverter
Locally
sourced
1) 1)
-48 V DC
120 –
230 V
AC
up to
3
up to
5.4
F Media
Gateway
Classic
BFD 761
40/1
450 x 310 x
315
6.6 – 14.0
2)
-48 V DC
7
G Fan Unit BFD 509
13/1
435 x 50 x
240
4.5
-48 V DC
1.2 2.2
H Media
Gateway
BFJ 901 03
440 x 44 x
260
3.2 100 – 240
VAC
12
56/1531-ASP 113 01 Uen J2 2008-07-17
