STARTING AND DRIVING
164
"Mode 2" cable variants table
The following table shows the list of the specific cable types and the amperages allowed for each country where the car is sold.
This amperage is the limit allowed when the charging power is set to the highest level.
Country group (*)
Electric vehicle
charging
connector type
Electric current
intensity (Ampere)
Type of domestic
power socket (**)
Cable length
(metres)
Notes
1
Type 2
13 CEE 7/7
6
–
2 10 G –
3 8 CEE 7/7 –
4 8 J –
5 6 K –
6 10 CEE 7/7
Specific cable for
Norway market
(*) The Country Group is indicated by the message "COUNTRY GROUP" on the label fig. 149located on the rear of the control
unit.
(**) Refer to the following pages for the type of power socket/plug.
NOTE To check the maximum electric current (Ampere) that can be consumed, refer to the label located on the back of the
control unit (see what is described and illustrated in the "charge status control unit" chapter).
