35
performance and safety, invalidate
the warranty and also result in non-
compliance of the car with type-approval
requirements.
REAR-VIEW
MIRRORS
INTERIOR MIRROR
The mirror is fitted with a safety device
that causes its release in the event of a
violent impact with the passenger.
Lever (A) fig. 33 can be used to move
the mirror to two different positions:
normal or antiglare.
33 F0S1107
ELECTROCHROMIC
REAR-VIEW MIRROR
(where provided)
Some versions have an electrochromic
mirror with automatic anti-glare
function.
There is an ON/OFF button
on the lower part of the mirror
for activating/deactivating the
electrochromic function. When the
function is active, a LED on the mirror is
active. When reverse is engaged, the
mirror is automatically set for daytime
use.
DOOR MIRRORS
22)
Proceed as follows:
select the mirror using selector (B)
fig. 34;
adjust the mirror using the joystick (A)
fig. 34 in the four directions.
34 AB0A0516
Folding the mirrors
When required (for example when
the mirror causes difficulty in narrow
spaces ) it is possible to fold the mirrors
manually moving them from the open
position (1) fig. 35 to the closed
position (2).
35 F0S1109
WARNING
22)
As door mirrors are curved, they may
slightly alter the perception of distance.
While driving the mirrors must remain in
position (1).
