CLIMATE CONTROL
SYSTEM
PASSENGER
COMPARTMENT AIR
DIFFUSERS
Side air diffusers
(A) fig. 44 fig. 45 - Fixed side air diffuser
(driver and passenger side).
44 AB0A0563
45 AB0A0564
(B) - Adjustable side air vents:
use device (C) to adjust the diffuser
to the desired position (up / down / left
/ right);
Central air vents
(A) fig. 46 - Adjustable and directable
central air vents:
use device (B) to adjust the diffuser
to the desired position (up / down / left
/ right);
46 AB0A0565
