KNOWING YOUR CAR
32
27 AB0A0557
Driver side and passenger side,
with position memory
To bring back the seat in its initial
position proceed as follows:
slide the seat back by pushing in the
lower part of the backrest as indicated
in fig. 27, taking care not to lift the
backrest into the vertical starting
position. In this way, slide the seat to
the locked position (movement 4);
now lift the backrest (movement 5)
into the vertical starting position until
you feel the click;
WARNING Using the strap (D) fig. 27
before locking the seat in its initial
position will cause the initial seat
position to be lost. In this case the
position of the seat must be restored
through lengthwise adjustment lever (A)
fig. 24.
Heated seats
(where provided)
Heated seats can only be activated by
soft touch controls on the Uconnect™
system with the ignition device in the
START position.
Auto On comfort
(where provided)
The electric heated steering wheel
is switched on automatically
whenever the motor is started and
the external temperature is lower
than or equal to 4.5°C. This function
is activated/deactivated on the
Uconnect™ system (see "Settings" in
the"Vehicle mode" paragraph in the
"Multimedia" section).
REAR SEATS
EXTENDING THE BOOT
18)
7)
The separate rear seats allow partial
fig. 28 or total fig. 29 boot extension.
28 AB0A0558
29 AB0A0559
Partial extension (50/50)
(for versions/markets, where provided)
Proceed as follows:
remove the parcel shelf, by releasing
it from its two side pins and pulling it
out;
remove the rear seat head restraints
(where provided); see the "Head
restraints" chapter in this section;
check that the seat belt is fully
extended and not twisted;
