57
54 AB0A0546
Closing
Press button (B) fig. 54 from the all
open position: the front glass panel will
move into the “vent” position. Press
button (B) again to reach the all closed
position of the roof.
ANTI-PINCH DEVICE
The sunroof has an anti-pinch safety
system capable of detecting the
presence of an obstacle whilst the roof
is closing. When this happens, the
system stops and the movement of the
roof is immediately reversed.
INITIALISATION
PROCEDURE
The sunroof must be reinitialised after
disconnecting the 12V battery or if the
corresponding protective fuse is blown.
Proceed as follows:
keep the button (B) fig. 54 pressed
so that the roof closes completely in
stages
after full closing, wait for the sunroof
motor to stop.
EMERGENCY OPERATION
If the electrical device for moving the
roof fails, the sunroof can be moved
manually proceeding as described
below:
55 F0S1331
for manual activation remove the
protective cap (A) fig. 55 from its
housing which is located on the internal
covering behind the sunshade
take the hex wrench provided from
the tool bag in the boot
insert the key provided into housing
(B) fig. 55and turn it clockwise to open
the roof or anticlockwise to close the
roof.
WARNING
30)
When leaving the car, make sure
to take the key with you to avoid the
risk of injury to those still inside the
car due to accidental operation of the
sunroof. Improper use of the roof can be
dangerous. Before and during operation,
always check that no-one is exposed to
the risk of being injured by the moving
sunroof or by objects getting caught or hit
by it.
IMPORTANT
12)
You are advised to use the sunroof
only at "vent" position if a transverse roof
rack is fitted.
13)
Do not open the sunroof if there is
snow or ice on it: you may damage it.
14)
Be careful not to hit objects on the roof
rack when you open the tailgate.
