18 “Operation and installation manual” - “Terra 360 Series 2 - CE”
EN
3.2.1 EVSE identification code
In the table is described the structure of the identification code of the EVSE.
TDC2L60 CE CJT 5N5 - 5N2 B - 0 EXAMPLE
Main product
Localization
EV charge cable connection
EV charge cable features
EV charge cable features
1)
User Interface features
Customized design
Field Description
TTT STPPP TTT is the “charger identification”:
TDC = Terra DC
S is the “product series”:
1 = Series 1
2 = Series 2
T is the “cabinet size”:
S = Small
M = Medium
L = Large
PPP is the “output power:
60 = 60 kW output power
360 = 360 kW output power
MM MM is the “localization”:
CE = for IEC market
UL = for North-American market
JP = for Japan market
XXX XXX is the “EV charging cable type:
CC =
CCS2 + CCS2
CCT = CCS2 + CCS2 + AC Type 2 socket 22 kW
2)
CJT = CCS2 + CHAdeMO + AC Type 2 socket 22 kW
3)
Y X V -Y X V Y is the “EV charging cable length:
5 = About 5 meters
X is the “EV charging cable cooling method”:
N = Non-cooled cable
V is the “EV charging cable current rating”:
1 = 150 A cable boost current rating
2 = 200 A cable boost current rating
5 = 500 A cable boost current rating
Z Z is the “User Interface specification”:
A = CCV VR payment terminal
B = CCV payment terminal with BS Payone
N = Nayax terminal
P = Payter P66 payment terminal
0 = If no option is selected (note that 15” display
and Mifare RFID reader are default)
V V is the “EVSE customization”:
C =
Customized color for a specific customer
Letters = Abbreviation of the customer name
0 = If the product is not customized
1 Field not present if the connector on the 2 EV charging cables are the same.
2 Terra 60 model only
3 Terra 60 model only
