ABB 2 Series - Output Current Vs Output Voltage Curve; Output Current Vs Output Voltage - Terra; Output Current (Peak) Vs Output Voltage - Terra

75Technical data
EN
10.5 Output current Vs output voltage curve
10.5.1 Output current Vs output voltage - Terra 60
Output current in function of output voltage
100
0
20
40
60
80
100
120
140
160
180
200
200 300 400 500 600 700 800 900
Output current [A]
Output voltage [V]
Output power in function of output voltage
100
0
10
20
30
40
50
60
70
80
90
100
200 300 400 500 600 700 800 900
Output power [kW]
Output voltage [V]
Single session
Dual session
(per outlet)
Single session
Dual session
(per outlet)
10.5.2 Output current (peak) Vs output voltage - Terra 360
Output current in function of output voltage
100 200 300 400 500 600 700 800 900
0
100
200
300
400
500
600
Output power in function of output voltage
100 200 300 400 500 600 700 800 900
0
50
400
Output current [A]
Output voltage [V]
Output power [kW]
Output voltage [V]
Single session
Dual session
(per outlet)
Single session
Dual session
(per outlet)
100
150
200
250
300
350
