SAFETY RELATED PARAMETERS
The Safety 266 pressure transmitters product meets the SIL2 requirements of IEC 61508 in low as well as high demand mode of ope-
ration. The total PFD in low demand mode for 10 years proof test interval in the worst case is less than the 15% of the range dened
in IEC 61508-1. The relevant numbers are stated in the table below:
266DX, 266VX,
266PX, 266HX,
266NX
266MXXR,
266CXXR,
266JXXR,
266RXXR
266MXXR,
266CXXR,
266JXXR,
266RXXR
(except range R)
266GXX, 266AXX
(except range C & F)
266GXX, 266AXX
(only range C & F)
λdd
2,62E-07 3,50E-07 3,94E-07 4,05E-07 4,13E-07
λdu
6,82E-08 4,10E-08 6,85E-08 6,85E-08 6,90E-08
λsd
3,37E-07 1,50E-08 2,39E-07 2,40E-07 2,40E-07
λsu
3,01E-07 1,42E-07 3,53E-07 3,42E-07 3,18E-07
HFT
0 0 0 0 0
T1
1 year / 10 years
(8760h / 87600h)
1 year / 10 years
(8760h / 87600h)
1 year / 10 years
(8760h / 87600h)
1 year / 10 years
(8760h / 87600h)
1 year / 10 years
(8760h / 87600h)
SFF
92,95% 93,63% 93,51% 93,51% 93,37%
Total Failure Rate
9,68E-07 1,08E-06 1,06E-06 1,06E-06 1,04E-06
MTBF
118 106 108 108 110
MTTR
8h 8h 8h 8h 8h
DC
D: 79%
C: 53%
D: 86%
C: 41%
D: 85%
C: 40%
D: 86%
C: 41%
D: 86%
C: 43%
PFD (1 year)
2,99E-04 3,01E-04 3,00E-04 3,00E-04 3,02E-04
PFH (1 yer)
6,82E-08 6,87E-08 6,85E-08 6,85E-08 6,90E-08
PFD (10 years)
2,98E-03 3,00E-03 2,99E-03 2,99E-03 3,01E-03
PFH (10 years)
6,82E-08 6,87E-08 6,85E-08 6,85E-08 6,90E-08
Testing time
< 20 s < 20 s < 20 s < 5 s < 70 s
ROM check time
< 30 s < 30 s < 30 s < 30 s < 70 s
