Commissioning
IM/265Gx/Ax-EN-07 265Gx, 265Ax 43
3
M00043
1
2
Fig. 15: Electronics area - Installing the LCD display
1 Position of the jumper or cable connector
for an LCD display with backlighting
2 Jumper holder for an LCD display with
backlighting
3 10-pin terminal strip for the LCD display
Note for 1
The jumper must be present if the backlighting option has not been selected for the LCD
display.
