Configuration
IM/265Gx/Ax-EN-07 265Gx, 265Ax 49
7.1.3 Transmitter with FOUNDATION Fieldbus communication
Parameter Factory settings
Measuring profile Pressure
Physical unit mbar/bar
Output scale 0% Measuring range lower limit (LRL)
Output scale 100% Measuring range upper limit (URL)
Output Linear
Upper alarm limit Measuring range upper limit (URL)
Upper warning limit Measuring range upper limit (URL)
Lower warning limit Measuring range lower limit (LRL)
Lower alarm limit Measuring range lower limit (LRL)
Hysteresis limit value 0.5 % of output scaling
PV filter 0.125 s
Address Not required
Any or all of the configurable parameters listed above - including the “Lower Range Value” and
“Upper Range Value” - can be changed using any FOUNDATION Fieldbus-compatible
configuration tool. Data regarding flange type and material, O-ring materials, and type of filling
liquid is stored in the device.
7.2 Configuration types
Pressure transmitters can be configured as follows:
• Configuration of the parameters for the “Lower Range Value” and “Upper Range Value”,
without an LCD display
• Configuration of the pressure transmitter using the LCD display (menu-controlled)
• Configuration with a handheld terminal
• Configuration using a PC/laptop via the graphical user interface (DTM)
