Configuration
48 265Gx, 265Ax IM/265Gx/Ax-EN-07
7.1.2 Transmitter with PROFIBUS PA communication
Parameter Factory settings
Measuring profile Pressure
Physical unit mbar/bar
Output scale 0% Measuring range lower limit (LRL)
Output scale 100% Measuring range upper limit (URL)
Output Linear
Upper alarm limit Measuring range upper limit (URL)
Upper warning limit Measuring range upper limit (URL)
Lower warning limit Measuring range lower limit (LRL)
Lower alarm limit Measuring range lower limit (LRL)
Hysteresis limit value 0.5 % of output scaling
PV filter 0.125 s
Address 126
Any or all of the configurable parameters listed above - including the “Lower Range Value” and
“Upper Range Value” - can easily be changed using the PC operation software SMART VISION
with DTM for 2600T. Data regarding flange type and material, O-ring materials, and type of
filling liquid is stored in the device.
