Section 2 Installation Installation in Cabinets

3BSE036351-510 A 147

Figure 50. Wall Cabinet – Dual Power Supply (Local/Field) Arrangement

Mains Breaker

Unit

SD831

24 V Distribution

(Units)

(Units in Cabinet)

SD831

(Field)

24 V Distribution

(Field Equipment)
