Installation in Cabinets Section 2 Installation

148 3BSE036351-510 A

Figure 51. Floor Mounted Cabinet (Horizontal Unit Arrangement)

Voting

Units

SS832

Breakers

Mains

SD832 Redundant

Power Supply Units

Redundant

Power

Supply Units

(Field

Equipment)

SD832
