See the rating information.Current
4, 8, or 12 kHzSwitching frequency
￭
Motor cable length
Operational functionality and motor cable length
The drive is designed to operate with optimum performance with the following
maximum motor cable lengths. The motor cable lengths may be extended with
output chokes as shown in the table.
Maximum motor cable lengthFrame
ftm
Standard drive, without external options
9830R0
16550R1
330100R2
330100R3
330100R4
With external output chokes
16450R0
24675R1
492150R2
492150R3
492150R4
Note: In multimotor systems, the calculated sum of all motor cable lengths must
not exceed the maximum motor cable length given in the table.
EMC compatibility and motor cable length
To comply with the EMC limits in the European EMC Directive (standard IEC/EN
61800-3), use these maximum motor cable lengths for the 4 kHz switching
frequency.
Maximum motor cable length, 4 kHzFrame
Class 3Class 2
ftmftm
With internal EMC filter
Technical data 129
