Quick installation and commissioning flowchart
SeeTask
Type designation label (page 32)
Identify the frame size: R0, R1, R2, R3 or R4.
Guidelines for planning the electrical
installation (page 43)
Technical data (page 97)
Plan the installation.
Check the ambient conditions, ratings and required
cooling air flow.
Unpacking the delivery (page 39)
Unpack and check the drive.
Grounding system compatibility
check (page 63)
If the drive will be connected to an IT (ungrounded)
system, make sure that the internal EMC filter is not
connected.
Mechanical installation (page 37)
Install the drive mechanically.
Routing the cables (page 52)
Route the cables.
Measuring the insulation (page 62)
Measure the insulation of the input cable, motor and
motor cable.
Connecting the power cables – IEC
(shielded cables) (page 67)
Connecting the power cables –
North America (wiring in con-
duits) (page 71)
Connect the power cables.
Connecting the control
cables (page 73)
Connect the control cables.
Installation checklist (page 81)
Examine the installation.
Refer to ACH180 Quick installation
and start-up guide
(3AXD50000955886 [English]) and
ACH180 Firmware manual
(3AXD50000955893 [English]).
Commission the drive.
22 Introduction
