Cleaning the heatsink
The drive module heatsink fins pick up dust from the cooling air. The drive runs
into overtemperature warnings and faults if the heatsink is not clean. When
necessary, clean the heatsink as follows.
WARNING!
Use the required personal protective equipment. Wear protective gloves and
long sleeves. Some parts have sharp edges.
WARNING!
Use a vacuum cleaner with antistatic hose and nozzle, and wear a grounding
wristband. Using a normal vacuum cleaner creates static discharges which
can damage circuit boards.
1. Stop the drive and do the steps in section Electrical safety
precautions (page 16) before you start the work.
2. Remove the module cooling fan(s). See the separate instructions.
3. Blow dry, clean and oil-free compressed air from bottom to top and
simultaneously use a vacuum cleaner at the air outlet to trap the dust. If there
is a risk of dust entering adjoining equipment, do the cleaning in another room.
4. Reinstall the cooling fan.
Replacing the cooling fans
Parameter 05.04 Fan on-time counter shows the running time of the cooling fan.
After you replace the fan, reset the fan counter. Refer to the firmware manual.
You can get replacement fans from ABB. Use only ABB specified spare parts.
￭
To replace the cooling fan for frame size R1
WARNING!
Obey the safety instructions of the drive. If you ignore them, injury or
death, or damage to the equipment can occur. If you are not a qualified
electrical professional, do not do installation, commissioning or
maintenance work.
1. Stop the drive and do the steps in section Electrical safety
precautions (page 16) before you start the work.
2. Press the two clips by fingers to open the fan cover.
Maintenance 87
