Valid markings5
Serial number of format MYYWWRXXXX, where6
M: Manufacturer designation
YY: Year of manufacture: 20, 21, 22, … for 2020, 2021, 2022, …
WW: Week of manufacture: 01, 02, 03, … for week 1, week 2, week 3, …
R: Hardware revision that starts from A.
XXXX: Running item number that starts each week from 0001.
￭
Type designation key
The type designation shows the specifications and configuration of the drive. The
table below presents the type code digits.
Sample type code: ACH180-04S-25A0-4
DescriptionCode
Product seriesACH180
Construction. 04=Module, IP2004
EMC, integrated STO and dual communications capabilityS
Size. See the ratings table in the technical data.25A0
Voltage rating.4
• 1=1-phase 208 V AC
• 2=3-phase 230 V AC
• 4=3-phase 380…480 V AC
Integrated control panel
The drive has an integrated control panel with a display, status LED and control
keys.
For quick reference, refer to ACH180 User interface guide (3AXD50000955909
[multilingual]).
Refer to ACH180 Firmware manual (3AXD50000955893 [English]) for information
on how to use the interface, start-up the drive and modify settings and parameters.
