Technical data
Contents of this chapter
This chapter contains the technical specifications of the drive including the ratings,
sizes and technical requirements, provisions for fulfilling the requirements for CE,
UL and other approval marks.
Ratings
￭
IEC ratings
Output ratings
Input
with
choke
Input
cur-
rent
ACH180-04S-...
Frame
size
Heavy-duty
use
Light-duty
use
Nominal use
Max.
current
P
Hd
I
Hd
P
Ld
I
Ld
P
n
I
n
I
max
I
1
I
1
kWAkWAkWAAAA
1-phase U
n
= 200 ... 240 V
R00.251.80.372.40.372.43.23.35.002A4-1
R00.372.40.553.50.553.74.34.86.903A7-1
R00.553.50.754.60.754.86.76.29.004A8-1
R10.754.51.16.61.16.98.19.212.606A9-1
R11.16.61.57.51.57.811.912.017.307A8-1
R11.57.52.29.32.29.813.517.021.809A8-1
9
Technical data 97
