ABB ACH180-04S - Frame R2

￭
Frame R2
4
11
6
10
7
3
1
2
5
9
8
12
13
PE connection (motor)8Input power connection terminal1
Fixed control terminals9
Integrated control panel (page 33)
2
Front cover10Motor connection terminal and brake
resistor terminal
3
Model information label11Cooling fan4
Cold configuration connection for CCA-0112Panel and PC tool port (RJ45)5
PE connection (input)13Type designation label6
EMC filter grounding screw7
