6.5 Toolkits, DressPack/SpotPack
General
All service (repair, maintenance and installation) instructions contain lists of tools
required to perform the specified activity. All special tools, that is all tools that are
not considered standard as defined below, are listed in their instructions
respectively.
This way, the tools required are the sum of the Standard Toolkit and any tools
listed in the instruction.
Standard toolkit
This standard toolkit contains a set of standard tools used for DressPack/SpotPack,
3HAC17290-7.
NoteToolArticle numberQty
-Socket head cap, 5-17mm-1
-Torx socket no: 20-60-1
For Harting connectorsPhillips screwdriver, small-1
For Harting connectorsFlat screwdriver, medium-1
For water connectors on water
and air unit
Ring-open-end spanner 8-19 mm-2
For Tension arm unit and water
connectors on DressPack
Open end wrench, 27 mm.-1
For water connectors on
DressPack
Open end wrench, 36 mm-1
Toolkit, water panel
This toolkit contains tools needed for water panel:
NoteToolArticle numberQty
For water panelSocket head cap 4 mm-1
For water panelRing-open-end spanner, 36 mm-2
Toolkit, cables
This toolkit contains tools needed for work with cables:
NoteToolArticle numberQty
Art. no. from HartingRemoval and Insertion tool for pins and
sockets
0999 000 0171 (D-
sub)
1
Art. no. from HartingRemoval tool for pins and sockets0999 000 0012
(HAN DD)
1
Art. no. from HartingRemoval tool for pins and sockets0999 000 0319
(HAN EE)
1
Art. no. from HartingInsertion tool for pins and sockets0999 000 0059
(HAN DD and HAN
EE)
1
Stripping pliers-1
Continues on next page
Product manual - DressPack/SpotPack IRB 8700 233
3HAC055802-001 Revision: B
© Copyright 2015-2017 ABB. All rights reserved.
6 Reference information
6.5 Toolkits, DressPack/SpotPack
