2.4.4.2 Fitting the cable package IRBDP SW6 LI, Lean ID
Location of the cable package IRBDP SW6 LI
The DressPack cable package IRBDP SW6 LI, is located as shown in the figure.
xx1500002651
Spare parts
NoteArticle numberSpare part
See DressPack cable pack-
age IRBDP SW6 LI on
page 238
Cable package IRBDP SW6
LI
Required tools and equipment
NoteArticle numberEquipment, etc.
Content is defined in section
Standard toolkit on page 233.
-Standard toolkit
Continues on next page
Product manual - DressPack/SpotPack IRB 8700 89
3HAC055802-001 Revision: B
© Copyright 2015-2017 ABB. All rights reserved.
2 Installation
2.4.4.2 Fitting the cable package IRBDP SW6 LI, Lean ID
