2.4.4 Installation of IRBDP SW6 LI, LeanID
2.4.4.1 Fitting attachments of the IRBDP SW6 LI, Lean ID
Location of the attachments
The attachments of the cable package are located as shown in the figure.
xx1500002597
Lower ball joint housingA
BracketB
Lower ball joint housingC
Lower ball joint housingD
BracketE
Lower ball joint housingF
Continues on next page
