FOXCST REFERENCE
FOX61xLEDE1 31
8 FOXCST reference
This section gives a complete reference of the managed objects, properties,
and commands of the LEDE1 functional unit of the FOX61x.
In this section, you will find the following information:
An introduction (section "Introduction" (page 31)),
Management commands and parameters for all available access points
(AP), starting with the unit AP (section "AP: / unit-x: LEDE1" (page 32)).
For a description on how to configure and bring into operation the LEDE1
unit and its main functions, please refer to section "Commissioning"
(page 23).
8.1 Introduction
Below, you will find a detailed description of all the configuration parameters
and operations belonging to the managed objects model (MOM) for the
LEDE1 service unit.
The Figure 9 shows the access point (AP) tree for the LEDE1 unit with its
managed objects.
Figure 9: MOM (managed object model) of the LEDE1 unit
With these managed objects (MOs) the following functions are covered:
<ap >
<ap >0...20
8
<ap>
port-y
<ap>
chan-z
0...31
unit-x: LEDE1
FOX61x
Table 7: Managed objects (MOs) for LEDE1
MO Description of the management functions
unit-x: LEDE1 Rxx
(lede1_r4b)
Restart of the unit, management of the unit ESW, labelling,
indication of the equipment status, display of inventory data,
presentation of logbooks.
The detailed properties are described in "AP: / unit-x: LEDE1"
(page 32).
port-y Management of the E1 ports. Configuration of the termination
mode and channel creation and deletion, performance monitor-
ing parameters, diagnostic loop activation.
