FOXCST REFERENCE
40 FOX61xLEDE1
8.3.4 AP: / unit-x / port-y, Fault Management
For the a description of the general aspects of the
 “Fault Management - Status”, and
 “Fault Management - Configuration”
management functions, please refer to "1KHW002466 FOXCST Operation".
The following counter groups are available for the LEDE1 E1 ports:
• “G.826” group, see section "AP: / unit-x / port-y, Performance Manage-
ment - G.826" (page 41).
• “P12 Events” group, see section "AP: / unit-x / port-y, Performance Man-
agement - P12 Events" (page 41).
The following counter intervals are available, depending of the counter
group:
Create Multiple
Channels
Start Index 0 … 32
The start index is the channel index of the first
channel.
0 is a reserved value used for the auto-assign-
ment of a channel index: The auto-assigned
index is the highest existing index number + 1.
In the FOXCST the default value is the autoas-
signed index number.
Number Of Chan-
nels
1 … 32 Number of channels to be created.
If the configured number of channels to be cre-
ated is higher than the available number of
unused time slots, the FOXCST creates no
channel, and displays a corresponding error
message.
n 1 … 32
Number of consecutive timeslots. If the struc-
tured P12 signal, the channel is belonging to,
uses CAS the timeslot 16 will be skipped auto-
matically, e.g. a channel with n = 19 and start
timeslot 1 will occupy timeslots 1 to 15 and 17 to
20 in a PCM30 signal.
The default value is the maximum of available
timeslots.
The start timeslot of the first channel is the low-
est available timeslot number.
Delete Channel … Open the FOXCST dialogue to delete one or all
channels.
Delete Channel Delete Channel All
Delete all channels.
All connections assigned to the channels will be
deleted also.
chan-1 … chan-31
Delete a channel.
All connections assigned to the channel will be
deleted also.
Table 12: AP: / unit-x / port-y, Configuration - Synchronization (con-
Operation Name Parameter Name Range Description / Details
Table 13: PM counter interval availability
Counter interval G.826 P12 Events
User Counter yes yes
