ABB FOX61 Series User Manual

FOXCST REFERENCE
32 FOX61xLEDE1
For each of the managed objects, properties and commands, the GUI “Tree
Views” are given.
This reference section comprises the management functions:
• Overview,
•Main,
• Configuration,
• Fault Management,
• Performance Management, and
• Status.
Most of the APs only offer a part of the management functions listed above.
The order of appearance of the management function descriptions is in
accordance with the APs in the FOXCST AP tree and the availability of the
management functions of each AP.
In the tables of the sections below, the parameter default values for proper-
ties are underlined
.
Please note:
For better legibility of numbers in this user guide, inverted commas are used
when the number’s size exceeds three digits (e.g. 40’000). In parameter
entry fields of the FOXCST, these inverted commas must not be entered.
Instead, the numbers are entered without these inverted commas (e.g.
40000).
Please note:
Screenshots presented in this reference are examples and show configura-
tions or data that may not correspond to the view you see when managing
your FOX61x equipment.
8.2 AP: / unit-x: LEDE1
8.2.1 AP: / unit-x, Overview
For a description of the
 “Overview - Alarms”, and
 “Overview - Cross Connections”
management functions, please refer to "1KHW002466 FOXCST Operation".
8.2.2 AP: / unit-x, Main
For the
 “Main - General”,
 “Main - Equipment”,
chan-z Channels are the connection termination points (CTP) for the
P0-nc and P12 traffic signal cross connections.
For the configuration of cross connections please
refer to
"1KHW002467 FOX61x TDM Services"
Table 7: Managed objects (MOs) for LEDE1 (continued)
MO Description of the management functions
